Name: SWC615 PM CS 200t Weighing Module – Heavy-Duty Carbon Steel Load Cell for Industrial Applications
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Modül SWC615 PM CS 200T
Availability: InStock

Ana sayfa Ürünler

SWC615 PM CS 200t Weighing Module – Heavy-Duty Carbon Steel Load Cell for Industrial Applications

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	Mettler Toledo
Model numarası:	Modül SWC615 PM CS 200T

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 set
Fiyat:	Pazarlık edilebilir
Ambalaj bilgileri:	karbon kutusu
Teslim süresi:	10-30 gün
Yetenek temini:	Ayda 2000 Takım

İletişim

Detaylı ürün tanımı

ürün:	Mettler Toledo yük hücresi	Maksimum kapasite:	440.000 lb (200.000 kg)
Malzeme:	Karbon çelik	metroloji:	OIML C1
Yük hücresi:	SLC820	Doğruluk:	Düşük
Koruma derecesi:	IP68/69K	Çevre / Malzeme:	Normal / karbon çeliği
Tehlikeli onay:	Atex ， fm	Kritiklik:	Durum izleme
Vurgulamak:	heavy-duty carbon steel load cell , industrial weighing module , Mettler Toledo load cell with warranty

SWC615 PM CS 200t Weighing Module – Heavy-Duty Carbon Steel Load Cell for Industrial Applications

A compression weigh module designed for industrial applications where its top plate and base plate compress under load. Ideal for direct installation on ground, piers, or structural beams. Commonly used in multiples for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing systems.

Key Features

Multi-Purpose Design
Suitable for static & dynamic tanks, hoppers, mixers & conveyors with high accuracy stainless hermetic load cell
Enhanced Safety Features
360° self-checking, dual lift-off & down-stops, ground strap, hazardous approvals & IP68 stainless load cell
Predictive Diagnostics
Monitors for overload, temperature changes, breaches, and zero drift to prevent system failures

Technical Specifications

Material	Carbon Steel
Material Number	30459518
Maximum Capacity	440,000 lb (200,000 kg)
Protection Rating	IP68/IP69k
Environment/Material	Normal/Carbon Steel
Hazardous Approval	ATEX, FM
Load Cell	SLC820
Accuracy	Low
Metrology	OIML C1
